| HY612 |
|
|
|
Size |
Ind
Code |
Min.Dual
Spacing |
Triangle Dimensions |
Loaded
Dimensions |
Tread Depth |
|
Overall Width |
Overall Diameter |
Static Load
Rad |
|
in |
mm |
in |
mm |
in |
mm |
in |
mm |
32nds |
mm |
|
14.00-24 |
E-3 |
17.7 |
450 |
14.8 |
375 |
53.9 |
1370 |
25.5 |
647 |
37.8 |
30 |
|
15.5-25 |
L-3 |
|
|
15.6 |
395 |
50.2 |
1275 |
22.8 |
579.9 |
31.5 |
25 |
|
16.00-25 |
E-3 |
20.2 |
513 |
16.9 |
430 |
58.9 |
1495 |
27.7 |
704.5 |
37.8 |
30 |
|
17.5-25 |
L-3 |
|
|
17.5 |
445 |
53.1 |
1350 |
24.0 |
610.65 |
32.1 |
25.5 |
|
17.5-25 |
L-3 |
|
|
17.5 |
445 |
53.1 |
1350 |
24.0 |
610.65 |
32.8 |
26 |
|
18.00-25 |
E-3 |
23.1 |
587 |
19.7 |
500 |
63.6 |
1615 |
29.9 |
758.5 |
40.3 |
32 |
|
18.00-25 |
E-3 |
23.1 |
587 |
19.7 |
500 |
63.6 |
1615 |
29.9 |
758.5 |
40.3 |
32 |
|
20.5-25 |
L-3 |
|
|
20.5 |
520 |
58.7 |
1490 |
26.3 |
668.05 |
35.9 |
28.5 |
|
20.5-25 |
L-3 |
|
|
20.5 |
520 |
58.7 |
1490 |
26.3 |
668.05 |
36.5 |
29 |
|
23.5-25 |
L-3 |
|
|
23.4 |
595 |
63.6 |
1615 |
28.3 |
719.3 |
39.7 |
31.5 |
|
23.5-25 |
L-3 |
|
|
23.4 |
595 |
63.6 |
1615 |
28.3 |
719.3 |
40.3 |
32 |
|
26.5-25 |
L-3 |
|
|
26.6 |
675 |
70.9 |
1800 |
31.3 |
795.15 |
44.1 |
35 |
|
26.5-25 |
L-4 |
|
|
26.6 |
675 |
70.9 |
1800 |
31.3 |
795.15 |
68.0 |
54 |
|
29.5-25 |
L-3 |
|
|
29.5 |
750 |
73.8 |
1875 |
32.5 |
825.9 |
54.2 |
43 |
|
29.5-29 |
L-3 |
|
|
29.5 |
750 |
77.8 |
1975 |
34.1 |
866.9 |
54.2 |
43 | |
|
|
